Lucent Technologies Galaxy Power System 4848/100

7 - 4 DC Distribution Panels Issue 5 June 2000

Figure 7-5: H569-434 G48 (ED83143-30 G5/6)

1000A DC Distribution Panel

Alarm Card

Five Positions for Large

U.S. Circuit Breakers

(125-600A) with Shunt)

Connects to

Charge Return Bus

Terminal Card

9" REF

(229mm)

Figure 7-6: H569-434 G52 (ED83143-30 G53)

600A DC Distribution Panel

Alarm Card

Connects to

Charge Return Bus

Ten Medium U.S.

Fuse Holders

(TPS Fuses, 1-60A)

6" REF

(152mm)
