Lucent Technologies Galaxy Power System 4848/100
Issue 5 June 2000 Specifications 9 - 5
Rated Service Entrance Surge Protector: It is important that the service entrance
surge protector (if provided) be coordinated with the internal surge protection and
that it clamps at a lower voltage then the internal protection. The internal protection
voltage and current characteristics of the 595A2 and 595B2 are as follows:
595A2
Phase to Phase MOV Conduction
Voltage Current
625 Vac (RMS) 0 A
940 Vpeak 1 mA
1650 Vpeak 100 A
595B2
Phase to Phase MOV Conduction
Voltage Current
320 Vac (RMS) 0 A
462 Vpeak 1 mA
810 Vpeak 100 A
Physical
Width 445 mm (17.5 in) rear of unit
Height 210 mm (8.25 in) rear of unit
Depth 470 mm (18.2 in) overall, less connector
Weight 29 kg (<65 lbs)
Environmental
Efficiency > 90% @ 100Adc - 200Adc output
current
Operating Temperature 0°C - 40°C
Operating Relative Humidity 5% - 90% non-condensing
Storage Temperature -40°C - +85°C
Storage Relative Humidity 5% - 90%
Altitude -50 to 4000 meters (Note: For altitudes
above 1500 meters, derate the
temperature by .656° Celsius per 100
meters.)
Audible Noise < 60dBA at room temperature, mounted
in cabinet
Heat Release:
54Vdc, 160A
54Vdc, 200A
Per Rectifier
854W [2915 BTU/hr]
1068W [3645.7 BTU/hr]
Table 9-B: 595 Series Rectifier Specifications
