Lucent Technologies Galaxy Power System 4848/100
Issue 5 June 2000 Battery Connection Panels 6 - 3
Figure 6-3: H569-434 G32 (ED83143-30 Group 30)
Battery Connection Panel
Figure 6-4: H569-434 G34 (ED83143-30 Group 41)
Battery Connection Panel
1500A Shunt
Terminal Card
Alarm Card
(2) NH3 Fuse Holders
Connects to
Charge Return Bus
9" REF
(229mm)
Two 600A Shunts
