Lucent Technologies Galaxy 4848/100 User Manual

Lucent Technologies Galaxy Power System 4848/100
9 - 2 Specifications Issue 5 June 2000
Physical
Width, Depth 600 mm, 600 mm (23.6 in. x 23.6 in.)
Weight (approximate, per cabinet) 250 kg (551 lbs.)
Height (cabinet only) 2134 mm (84.0 in.)
Height (cabinet with link bus bar) 2274 mm (89.5 in.)
Environmental
Maximum Input Current, per cabinet 120 amperes per phase, 3-wire
Heat Release, per cabinet
4 rectifiers @ 1068W each
2
5 rectifiers @ 1068W each
2
6 rectifiers @ 1068W each
2
2
54Vdc, 200A output, per rectifier
4272W [14,583 BTU/hr]
5340W [18,228 BTU/hr]
6408W [21,874 BTU/hr]
Operating Temperature 0°C to 40°C
Operating Release Humidity 5% - 95%
Units Per Initial Cabinet
Rectifiers 0 - 6
Controller 1
Battery Disconnect Modules 1 - 3
DC Distribution 1 - 6
(maximum of 5 with battery disconnect)
Units Per Growth Cabinet
Rectifiers 0 - 6
Battery Disconnect Modules 0 - 1
DC Distribution 1 - 6
(maximum of 5 with battery disconnect)
Table 9-A: Galaxy Power System 4848/100 Specifications

Lucent Technologies Galaxy 4848/100 Specifications

General

Brand	Lucent Technologies
Model	Galaxy 4848/100
Category	Power Supply
Language	English
