LXNAV NANO4 - FLARM Connection Options

Rev #2 Version 3.00 August 2020
Page 65 of 80
7.2 Connecting a FLARM to the NANO
4
7.3 Connecting a FLARM to the NANO
4
using the NanoPower-FL
7.4 Connecting a FLARM/PFlarm to the NANO
4
using the NanoPower-PF
Nano Power
Must be connected to 12V
CC-NP-IGC
cable
USB cable
NANO
4
Nano Power-FL
Gets 12V from Flarm
USB cable
NANO
4
Nano Power-PF
Gets 12V from PowerFlarm
PowerFLARM
FLARM
USB cable
NANO
4
FLARM
12V power supply
12V power supply
12V power supply
