MAINTENANCE/SERVICE
Fuels, Fluids and Lubricants (continued)
~'V'STEM
CAPACITIES
Fuel Tank
Hydraulic System: Total (varies with options)
Reservoir Capacity
Bevel Gear Box
Power Wheel
Engine Cooling System: Gas
Diesel
Gas Engine Crankcase: Less Filter
With Filter
Diesel Engine Crankcase: Less Filter
With
Filter
Air Conditioning System:
Refrigerant (R-12)
Mechanical Governor (Gas Engine)
GREASING
n-tE WINDROWER
TRACTOR
See "Fuels, Fluids and Lubricants• for recom-
mended greases.
The following greasing points are marked on the
windrower
by
decals showing a grease gun (A),
and grease interval
(B)
in hours
of
operation. Use
the hour meter in the cab and the "Maintenance
Checklist• provided
to
keep a record
of
scheduled
maintenance.
Procedure:
SJ.
193 L
75
L (approx
.)
57 L
500
ml
840
ml
20 L
18 L
4.7 L
5.7 L
9.5 L
10.4 L
1.4 kg
75
to
90
ml
U.S.
51
gal.
20 gal. (approx.)
15.2 gal.
17 oz.
28.4 oz.
5.3 gal.
4.8 gal.
5
qts
.
6
qts
.
10
qts
.
11
qts
.
3 lbs.
2Yz
to
3 oz.
1.
Wipe grease fitting with a clean cloth before
greasing,
to
avoid injecting dirt and grit.
SAMPLE
GREASE
DECAL
2.
Inject grease through fitting with grease gun
until grease overflows. Inject grease slowly
to
prevent
seal
damage.
3. Leave excess grease on fitting to keep out dirt.
4.
Replace any loose
or
broken fittings
Immediately.
5. If fitting will not take grease, remove and clean
thoroughly. Also clean lubricant passageway.
Replace fitting if necessary.
47
