215626 16 Revision A
Figure 2.10: M155/M155E4 Hose Configuration

3
5
$
% 3
&
5
A - Hose from Port P on DWA Drive Manifold to Pump (not visible) B - Cooler Bypass Relief Valve
C - Hose from Port R2 on DWA Drive Manifold to Cooler Bypass Relief Valve P - Port P
SETUP INSTRUCTIONS
