Mahr Digimar 816 CL User Manual

13
Mahr GmbH • Digimar 816 CL
EN
1.3 Description and explanation of the height measuring instrument
1.3.1 Height measuring instrument
1 Transport protection screw
2 Mount for probing element carrier
3 Probing element carrier
4 Contact point
5 Limit (stop) plate
6 LED indicator for battery power
7 Handle for manually positioning the slide
8 Display
9 Keypad
10 Hand grip
11 Transport handle
12 Switch for activating the air bearings
13 Socket for the battery charger
14 ON/OFF switch
15 Rechargeable battery compartment
16 Interface for data output
17 Battery charger
1
8
9
12
10
7
5
3
4
2
11
6
15
13
14
16 17
Euro US
UK
