Mahr GmbH • Digimar 816 CL
EN
2.4 First measurement
2.4.1 Contacting a plane from above
– Position the probe
– Press the „Contact from above“ key to start the measuring
procedure
In the display will appear the measured value
Description / Sequence Symbols / Pictures
4
2.4.2 Measuring a bore
– Position the probe in the bore (not in the center / eccentrically)
– Press the „Measure bore“ key to start the measuring procedure
– The probe will automatically travel upwards; the bore is contacted
from below
2
