Mahr Digimar 816 CL User Manual

46
Mahr GmbH • Digimar 816 CL
EN
Description / Sequence Symbols / Pictures
– Connect either the data connection cable Opto RS232
(Order no. 4346020, without an adapter) or USB cable
(Order no. 4346023) to a PC and the height measuring
instrument.
– Start the VariFlashEasy program
– Set up configuration (when using a COM interface, generally
select COM1)
Note:
When using a USB cable a virtual COM interface can be generated
under Control Panel - System - Hardware - Device Manager - Ports -
Serial-Port. The COM Port number, for example COM2 can be
assigned in the Serial Interface.
– Select the actual program file
– Press the push button „Software update“
– The progress of the download will be indicated
– The transmission software update is a success.
