INTRODUCTION CD3340B/YB4411
1-2
Published 04/07/2015 Control # 569-00
SPECIFICATIONS
Table 1-1
Engine
Diesel Engine
Make and Model.............................................................. Cummins QSB3.3 Tier 4i diesel
Type of Aspiration............................................................ Turbocharged
Horsepower..................................................................... 100 hp @ 2600 rpm
Low Idle Speed................................................................ 800 rpm
Maximum Engine Speed ................................................. 2860 rpm
Boom
Construction.................................................................... Telescopic, welded box sections
Number of Sections......................................................... Three section, full proportional
Reach.............................................................................. 4.22 m (13 ft-10 in) to 10.1 m (32 ft-10 in)
Mast Rotation — 360°
Mast Bearing (Diameter) ................................................. 860.6 mm (33.884 in)
Swing Drive Mechanism.................................................. Hydraulic motor driven gearbox
Swing Speed ................................................................... 2 rpm
Electrical
Type ................................................................................ 12 volts, direct current
Alternator......................................................................... 120 amps
Battery............................................................................. 90 amp/hr
Fuel Tank
Capacity .......................................................................... 64 L (17 gal)
Hydraulic System
Pump............................................................................... Variable displacement piston pump
Main Control Valves ........................................................ Four-section, pressure compensated, pilot actuated
Swing Motor .................................................................... Single section, gerotor-type
Hoist Motor...................................................................... Fixed displacement, axial piston
Hydraulic Filters ..............................................................
One 10-micron filter in line from valves
One 30-mesh suction filter inside hydraulic tank
Hydraulic Cylinders .........................................................
Double-acting cylinders for lift, telescope, steering and
outriggers
Hydraulic Tank.................................................................
130.6 l (34.5 gal) capacity, steel construction with
internal baffles
Wire Rope
Wire Rope (Main Hoist)
Diameter.......................................................................... 14.3 mm (9/16 in)
Type ................................................................................ 6 x 9 Bright EEIPS-IWRC
Length: ............................................................................ 36.58 m (120 ft)
Reference Only
