Manitowoc Grove CD3340B User Manual

GROVE 4-51
CD3340B/YB4411 HYDRAULIC SYSTEM
4
Published 04/07/2015 Control # 569-00
UNDER DECK WINCH
The under deck winch is connected to the front outrigger
control manifold. Hydraulic oil flows through an electrically
activated three position directional control valve to provide
directional control and a two-position control valve to supply
oil flow.
Reference Only
