MAINTENANCE CD3340B/YB4411
5-40
Published 04/07/2015 Control # 569-00
unpainted fasteners and hardware, valves, slew ring
fasteners and all bare metal surfaces.
• Boom applications areas are; pivot pins, hose end and
fittings, jib pins and shafts, all bare metal surfaces,
headache ball pins/ hook block pins and fasteners.
• All hardware, clips, pins, hose connections not painted
will have treatment applied.
FIGURE 5-78
8510
1
2
3
4
5
6
8
7
10
12
13
14
16
15
11
9
