GROVE 6-9
CD3340B/YB4411 ENGINE AND ENGINE SYSTEMS
6
Published 04/07/2015 Control # 569-00
FIGURE 6-4
8472-1
Item Description
11. Flat Washer
12. Flat Washer (6)
13. Socket Head Capscrew (2)
14. Socket Head Capscrew (2)
15. Hex Head Capscrew
16. Socket Head Capscrew
17. Socket Head Capscrew (6)
18. Hex Head Capscrew (4)
19. Lockwasher (4)
20. Flat Washer (4)
21. Hex Head Capscrew (2)
22. Lockwasher (2)
23. Socket Head Capscrew (4)
Item Description
1. Primary Hydraulic Pump
2. Drive Coupling
3. Pump Mount Plate
4. Coupling Sleeve
5. Engine Coupling Hub
6. Pump Coupling Hub
7. Hex Head Capscrew (6)
8. Pump Support Bracket
9. Socket Head Capscrew (4)
10. Spacer (2)
Reference Only
