Manitowoc Grove CD3340B User Manual

GROVE 4-43
CD3340B/YB4411 HYDRAULIC SYSTEM
4
Published 04/07/2015 Control # 569-00
a0962
FIGURE 4-36
Item Description
1 Flat Head Screw (3)
2Flange
3 O-ring*
4 Thrust Washer*
5 Swivel Housing
6 Seal (2)*
7Swivel Stem
8 Seal (8)*
9 O-ring (8)*
* Included in Seal Kit
Reference Only
