Maintenance work on the carrier
7.6 Transmission
7 - 48 3 302 744 en Maintenance manual
GMK5250L
09.03.2018
Topping up the oil
• Remove the drain plug (1).
• Remove the hose (2).
• Top up oil through the hole (2) until oil
comes out of the hole (1).
• Replace the gasket and tighten the drain
plug (1) – torque 25 Nm (18.4 lbf ft).
• Add an additional 1.5 l (0.4 gal) oil through
the hole (2).
• Attach the hose (2).
Inspections after
the oil change
After changing oil, check for leakage:
• Start the engine and let it idle in neutral N.
• Check the screw plugs (1) to (3) for leakage.
• Check the hoses and connections on the oil
cooler.
