Maintenance work on the superstructure
8.7 Main boom
8 - 48 3 302 744 en Maintenance manual
GMK5250L
09.03.2018
8.7.2 Lubricating the telescopic sections
Grease, spare
parts, tools
– A grease gun for the lubricating nipples on the locking pins.
– A grease gun for the grease nipples on the upper telescopic slide faces.
– A brush or roller for the outer, upper and lower telescopic slide faces.
H
The Manitowoc Crane Group Germany GmbH recommends pneumatic
grease spray guns for more effective lubrication of the telescopic slide
faces:
Prerequisites – The truck crane must be level.
– The hook block must be unreeved.
– The main boom must be completely retracted and lowered into horizontal
position.
– A rigging mode must be created with a telescoping status which satisfies
the lifting capacity table necessary for maintenance;
à Lifting capacity
table
; Section Telescoping sequences for greasing the boom.
– The RCL code for the current rigging mode must be entered.
H
If initially you set up a rigging mode under which the telescope statuses
56/100/0/0/0/0 are available in the context of the associated lifting capacity
table, this rigging mode allows you to perform the complete maintenance
work on the main boom.
Designation GROVE part no.
Lubricant for the locking pins:
RHUS SW 2, 1 kg can
03325215
Slide paste for the telescopic slide faces:
PAL1, 25 kg bucket
02314698
Designation GROVE part no.
Grease spray gun, complete:
Mobile, external compressed air connection
required
03325445
Spray extension, length 2 m, splittable 04159862
Manual grease spray gun for cartridge:
Via the tyre inflator connection on the truck
crane
03329027
25 m hose for manual grease spray gun: 03329072
Slide paste for the telescopic slide faces:
PAL1, 400 ml cartridge, refillable
03329071
