Manitowoc Grove GMK 5250L Maintenance Manual

Spare parts required for maintenance
11.4 Spare parts for the superstructure
11 - 8 3 302 744 en Maintenance manual
GMK5250L
09.03.2018
11.4 Spare parts for the superstructure
Assemblies and spare parts
Superstructure
GROVE part
number
Quantity, in single parts
For maintenance interval
W M 1 M 3 M 6 M 12
Hoists
Sight glass with hoses; complete
04161717 (2) (if damaged) (2)
Slewing gear
Gasket 10 x 14 Cu DIN 7603
00117125 (3) (if damaged)
Gasket 10 x 14 Cu DIN 7603 00117125 3
Gasket 14 x 20 Cu DIN 7603 00117132 3
Hydraulic system
Filter 1 (only clean)
Packing set
04156358 (1)
04165792 (1)
Filter 1
Packing set
04156358
at every oil change
and when the symbol lights up
1
04165792 1
Filter 2
Housing packing set
03142356 1
03326049 1
Filter 3 03249527 1
Ventilation filter 03134932 1
Hoist ropes
Cover gasket
02315305
1 (if damaged)
for every rope change on the hoist
Cable drums
Cover gasket for cable drum 1
Cover gasket for cable drum 2
03325575
(if damaged)
(1)
03138894 (1)
Air conditioning system
Pollen filter for crane cab 04163620 1
Other maintenance work
Windscreen wiper blade
03268512 (1)
(if damaged)
Roof wiper blade 03326121 (1)
