Maintenance work on the carrier

7.10 Wheels

09.03.2018

Maintenance manual 3 302 744 en 7 - 75

GMK5250L

7.10.3 Checking that the wheel nuts are tight

Spare parts and

tools

– Torque wrench for 650 Nm (480 lbf ft).

Prerequisites – The engine must be switched off and secured against unauthorised use;

à p. 2 - 3.

Checking the

wheel nuts

• Check the wheel nuts and the pressure

plates for damage.

• Replace any damaged wheel nuts or pres-

sure plates.

• Check the wheel nuts in sequence (1-12) for

a tight fit – torque 650 Nm (480 lbf ft).

M 1

Designation Quantity

per wheel

GROVE part no.

Wheel nut with pressure plate

for steel rims

12 01207756

Wheel nut with pressure plate

for aluminium rims

12 7659100000
