Maintenance work on the carrier
7.2 Symbols for maintenance work
09.03.2018
Maintenance manual 3 302 744 en 7 - 9
GMK5250L
7.2 Symbols for maintenance work
CCS • Check the symbols on the CCS start menu (Crane Control System) in the
driver's cab each day before starting work.
• The Start menu shows the most important measurements and the
Maintenance submenu shows all the outstanding warning messages;
à Operating manual.
Maintenance
submenu
If one of the symbols is displayed, you must carry out the appropriate main-
tenance work:
– Oil pressure; à p. 7 - 11,
– Coolant level; à p. 7 - 16,
– Air filter; à p. 7 - 15,
– Angle gear; à p. 7 - 54,
– Hydraulic oil filter; à p. 7 - 115,
– AdBlue system; à p. 7 - 34,
s
