Manitowoc Grove GMK 5250L Maintenance Manual

Maintenance work on the superstructure
8.4 Slewing gear
09.03.2018
Maintenance manual 3 302 744 en 8 - 19
GMK5250L
8.4.4 Changing the oil/checking the oil
• Comply also with the à Run-in regulations, p. 4 - 1.
Oil, spare parts,
tools
– Receptacle, approx. 5 l (1.5 gal); à p. 2 - 4.
Prerequisites – The truck crane must be level and in on-road mode; à Operating manual.
– The engine must be switched off and secured against unauthorised use;
à p. 2 - 3.
Changing the oil
• Always change the oil in all slewing gears.
s
M 12
Gear oil in
litres (gal)
Designation to
DIN 51502
Specification
Classification
GROVE part no.
0.9 (0.24)
for each
slewing gear
C - LPF MIL-L 2105 B
API-GL-4/5
Viscosity:
SAE 75 W-90 EP
ISO - VG 220
02313611
Synthetic oil;
do not mix this
with mineral-
based oils.
Designation Quantity GROVE part no.
Gasket 10 x 14 Cu DIN 7603 3 00117125
Gasket 14 x 20 Cu DIN 7603 3 00117132
O
Risk of environmental damage due to leaking consumables.
Always let consumables drain into suitable receptacles. Wipe up any con-
sumables that have leaked.
Store/dispose of consumables and any soaked equipment properly.
Ask about the applicable regulations.
