Maintenance work on the carrier
7.3 Engine
7 - 24 3 302 744 en Maintenance manual
GMK5250L
09.03.2018
7.3.9 Changing the oil and oil filter
Oil, spare parts,
tools
– Receptacle, approx. 40 l (11 gal); à p. 2 - 4.
– Torque wrench for torque of 55 Nm (40.5 lbf ft).
– Connecting piece and hose (tool box); à p. 7 - 112.
Prerequisites • Find out the prescribed oil specification and about the necessity of short-
ening the maintenance interval under special operating conditions;
à Engine manufacturer's documentation.
• Find out about the safety instructions and the sequence of steps to change
the oil and the oil filter;
à Engine manufacturer's documentation.
– The truck crane must be level.
– The engine must be switched off and secured against unauthorised use;
à p. 2 - 3.
Changing
If a valve is already mounted on the oil pan:
Engine oil in
litres (gal)
Designation to
DIN 51502
Specification
Classification
GROVE part no.
39 (10.3) HD - CD MIL-L 2104 C
DB 228.5
SAE 5 W-30
03329588
Designation Quantity GROVE part no.
Oil filter 1 04161614
Cover gasket 1 03328606
Gasket for oil drain plug 1 04161531
O
Risk of environmental damage due to leaking consumables.
Always let consumables drain into suitable receptacles. Wipe up any con-
sumables that have leaked.
Store/dispose of consumables and any soaked equipment properly.
Ask about the applicable regulations.
O
Risk of environmental damage due to leaking consumables.
If a valve is mounted on the oil pan, use the delivered connecting piece with
hose and a receptacle with adequate capacity to drain the oil.
