Spare parts required for maintenance
11.2 Lighting
11 - 4 3 302 744 en Maintenance manual
GMK5250L
09.03.2018
SUPERSTRUCTURE LIGHTING:
Yellow marker lights:
(left and right on the main boom head)
– Marker light; complete 03329569 LED
Red rear marker lights:
(on the turntable)
– Marker light; complete 03329492 LED
Yellow rotating beacon:
(on the turntable)
– Rotating beacon; complete 04156048
Inside light:
(in the crane cab)
– Cab light 01207144 R10W 10
– Reading light 00439055 P25-1 21
Spotlight, angular-shaped, permanently installed:
(at the front of the crane cab)
– Filament lamp 01573349 H3 24V 70
Spotlight, electrically adjustable:
(at the front of the main boom)
– Halogen bulb 03142726 8GS009028001 35
Installation point GROVE part
number
Designation Power (W)
