MAINTENANCE AND LUBRICATION GRT9165 OPERATOR MANUAL
6-14 Published 7-23-2020, Control # 668-02
Item
Lube Point
Description
Figure No.
Approved
Lubricant
Approximate
Capacity
Service Interval
Service
Application
Drive Train (Continued)
5a
Transmission and
Torque Converter
Locations
Figure 6-2 J
44.5 L
(11.75 gal)
Every 10 hours/daily
CHECK fluid level
See NOTE 8.
See NOTE 9.
See NOTE 10.
FILL transmission
sump to FULL on
DIPSTICK
See NOTE 12.
PERFORM after first
50 hours of service,
and
REPEAT after
another 50 hours for
a total of 100 hours of
service
DRAIN transmission
sump
See NOTE 11.
REPLACE
transmission and
torque converter
filter
See NOTE 11.
CLEAN magnetic
drain plug
INSTALL magnetic
plug in drain port
FILL transmission
sump to FULL on
DIPSTICK
Then every
1000 hours, or
6 months, thereafter,
whichever interval
comes first
DRAIN transmission
sump
See NOTE 11.
REPLACE
transmission and
torque converter
filter
See NOTE 11.
FILL transmission
sump to FULL on
DIPSTICK
See NOTE 12.
NOTE 8: Check Transmission Fluid level using the transmission oil dipstick located on the side of carrier adjacent to the
hydraulic tank. Check fluid level with boom fully retracted and lowered, and all outrigger cylinders retracted.
NOTE 9: Only check the fluid level when transmission is at operating temperature.
NOTE 10: Level should be checked with engine running at 850 rpm idle and torque converter fluid temp at 65°C to 90°C
(150°F to 200°F). To bring fluid temperature to this range, it is necessary to work the crane or stall the converter.
