SET-UP AND INSTALLATION RT9130E-2 OPERATOR MANUAL
4-6
Published 3-1-2018, Control # 559-03
FIGURE 4-7
10 PARTS LINE
Upper Boom Nose Sheaves
To M a i n H o i s t
Bottom Boom Nose Sheaves
Hookblock Sheaves
Boom Nose Dead End
7177-3
One Part Line Using Boom
Extension Shown at 20° Offset
6453-3
One Part Line Using Boom
Extension Shown at 40° Offset
