MAINTENANCE AND LUBRICATION RT9130E-2 OPERATOR MANUAL
5-30
Published 3-1-2018, Control # 559-03
Item
Lube Point
Description
Figure No.
Approved
Lubricant
Lube
Capacity
Lube Interval Application
Hoist
90 Main Hoist Figure 5-11
AGMA
Extreme
Pressure Gear
Lubricant
6829100213
22 qt
(20.8 l)
• Check and fill every
50 hours or weekly
• Drain and fill every
1000 hours or 12
months
Oil level must be
visible in the sight
glass. (See note)
91 Auxiliary Hoist Figure 5-11
AGMA
Extreme
Pressure Gear
Lubricant
6829100213
22 qt
(20.8 l)
• Check and fill every
50 hours or weekly
• Drain and fill every
1000 hours or 12
months
Oil level must be
visible in the sight
glass. (See note)
NOTE: To check hoist oil, ensure hoist is level and the fill plug is horizontal and centered in access hole at the 9:00 position.
The oil must have settled for 20 minutes with the temperature in 21°C ± 7°C (70°F ± 20°F) range. Variations in oil
temperature will cause oil level to fluctuate.
If oil level is not visible in sight glass, the hoist may be under filled. Oil escaping from vent plug is an indication the
hoist may be overfilled.
92
Cable Follower
(Arms)
Figure 5-11
EP-MPG
Extreme
Pressure
Multipurpose
Grease
6829003477
Thoroughly
coat
250 hours or 3 months Spray on
NOTE: Lubricate more frequently than interval indicated in table if environmental conditions and/or operating conditions
necessitate.
