SAFETY INFORMATION RT9130E-2 OPERATOR MANUAL
2-40 Published 3-1-2018, Control # 559-03
faulty holding valves. If leaking seals or faulty
holding valves are suspected to be the problem,
refer to Service Bulletin dealing with testing
telescope cylinders. (Service Bulletin 98-036
applies to TMS700 and Service Bulletin G06-005A
applies to RT890 and RT9130.
Table 2-8: Boom Drift Chart (Cylinder length change in inches)
Table 2-9 Boom Drift Chart (Cylinder length change in millimeters)
OVERLOAD INSPECTION
This information supplements the Rated Capacity Limiter
(RCL) manual supplied with each Grove crane.
When the RCL system has acknowledged an overload on
your crane, or the crane has been subjected to a collision
with external obstacles, you must carry out specified
inspections on the crane.
Coeff. = 0.00043
(in
3
/in
3
/ °F)
STROKE Temperature Change (°F)
(FT.)102030405060708090100
5 0.260.520.771.031.291.551.812.062.322.58
10 0.52 1.03 1.55 2.06 2.58 3.10 3.61 4.13 4.64 5.16
15 0.77 1.55 2.32 3.10 3.87 4.64 5.42 6.19 6.97 7.74
20 1.03 2.06 3.10 4.13 5.16 6.19 7.22 8.26 9.29 10.32
25 1.29 2.58 3.87 5.16 6.45 7.74 9.03 10.32 11.61 12.90
30 1.55 3.10 4.64 6.19 7.74 9.29 10.84 12.38 13.93 15.48
35 1.81 3.61 5.42 7.22 9.03 10.84 12.64 14.45 16.25 18.06
40 2.06 4.13 6.19 8.26 10.32 12.38 14.45 16.51 18.58 20.64
45 2.32 4.64 6.97 9.29 11.61 13.93 16.25 18.58 20.90 23.22
50 2.58 5.16 7.74 10.32 12.90 15.48 18.06 20.64 23.22 25.80
55 2.84 5.68 8.51 11.35 14.19 17.03 19.87 22.70 25.54 28.38
60 3.10 6.19 9.29 12.38 15.48 18.58 21.67 24.77 27.86 30.96
Length change in inches = Stroke (Ft.) X Temperature Change ( °F) X Coeff. (in
3
/in
3
/ °F) X 12 in/ft
Coeff. = 0.000774
(1/ °C)
STROKE Temperature Change (°C)
(m) 5 10 15 20 25 30 35 40 45 50 55
1.5 6 12 17 23 29 35 41 46 52 58 64
3 1223354658708193104116128
4.5 17 35 52 70 87 104 122 139 157 174 192
6 23 46 70 93 116 139 163 186 209 232 255
7.5 29 58 87 116 145 174 203 232 261 290 319
9 35 70 104 139 174 209 244 279 313 348 383
10.5 41 81 122 163 203 244 284 325 366 406 447
12 46 93 139 186 232 279 325 372 418 464 511
13.5 52 104 157 209 261 313 366 418 470 522 575
15 58 116 174 232 290 348 406 464 522 581 639
16.5 64 128 192 255 319 383 447 511 575 639 702
18 70 139 209 279 348 418 488 557 627 697 766
Length change in mm = Stroke (m) X Temperature Change ( °C) X Coeff. (1/ °C) X 1000 mm/m
