RT9130E-2 OPERATOR MANUAL MAINTENANCE AND LUBRICATION
Published 3-1-2018, Control # 559-03
Item
Lube Point
Description
Figure
No.
Approved
Lubricant
Lube
Capacity
Lube Interval Application
Drive Train (continued)
23
Coolant Strainer
(Cab Heater)
Figure 5-4 --- ---
Clean strainer screen
after first 100 hours and
every 2000 hours or 12
months thereafter.
Close shutoff valves.
Unscrew hex plug to
clean filter.
24a
24b
Air Cleaner
Filters
Pre-cleaner
Figure 5-4 --- ---
• Replace primary filter
element when either
fault code 5576 or
3341 is displayed.
Replace secondary
filter every third time
primary filter is
replaced.
• In severe dust
conditions the pre-
cleaner may need to
be serviced.
Front of left rear
fender.
25a
25b
Water Separator
Fuel Filter
Figure 5-4 --- ---
• Drain water trap
every 10 hours or
daily.
• Change filter every
500 hours or 6
months.
Primary fuel/water
separator is located
beside the fuel tank
26a
26b
Driveline - Slip
Joints
Figure 5-4
EP-MPG
Extreme
Pressure
Multipurpose
Grease
6829003477
Until
grease
extrudes
500 hours or 3 months 3 grease fittings
27
Retarder
(Optional)
Figure 5-4 --- --- After 2000 hours
Grease using hand
grease gun
NOTE: Grease using hand grease gun until grease comes out of vent tube outlet located near grease nipple.
CAUTION: DO NOT OVER GREASE.
To Next Page
