MAINTENANCE AND LUBRICATION RT9130E-2 OPERATOR MANUAL
5-24
Published 3-1-2018, Control # 559-03
WARNING
Crane Setup for Items 74 & 75: Crane to be set up on firm level surface with fully extended outriggers and 40,000 lb
counterweight installed. Ensure crane is level. Boom must be directly over the front and the house lock engaged. Set boom
angle at zero degrees. No load is permitted on the boom. The weight of the hookblock, overhaul ball and rigging must not be
supported by the boom. Do not extend the boom until the weight of these components is totally removed from the boom.
74
Internal Side
and Bottom
Wear Pads
(Inner
Sections)
Figure 5-8
EP-MPG
Extreme
Pressure
Multipurpose
Grease. Note:
(Down to -9°C
(15°F) use
6829015304).
[Below -9°C
(15°F) use
6829003477].
Thoroughly
coat all
areas the
wear pad
moves on
250 hours or 3 months
14 places by brush;
through access holes
with boom in extended
position
See Table 5-1, page 5-36 at the end of this sections for how to access lubrication points 74 & 75
75
Boom Section
Upper Wear
Pads
Figure 5-8
EP-MPG
Extreme
Pressure
Multipurpose
Grease. Note:
(Down to -9°C
(15°F) use
6829015304).
[Below -9°C
(15°F) use
6829003477].
Until
grease
extrudes
50 hours or 1 week
8 grease fittings;
through access holes
with boom in extended
position
Item
