TMS700E SERVICE MANUAL ELECTRIC SYSTEM
Troubleshooting Lights
1. Check lamp first. Replace any damaged lamp.
2. If all lamps in a circuit do not work, suspect the fuse and
switch. Replace fuse if necessary.
3. Check the switch and circuit for continuity problems and
other problems. Repair any faulty switch or other
component. Repair wiring if faulty.
Carrier
The following carrier circuit designs apply (Table 3-9)
(connecting wiring and passage through swivel slip ring -- as
applicable -- is understood):
Table 3-9
Superstructure
The following superstructure circuit designs apply (Table 3-
10) (connecting wiring and passage through swivel slip ring -
- as applicable -- is understood):
Table 3-10
Troubleshooting Gauges and Meters
NOTE: When operating from either cab, the gauges and
meters in the other cab will function also. The
gauges share a common sender and therefore
both gauges must be powered, When operating
from the carrier, F5 supplies the power and when
operating from the superstructure, F9 supplies the
power.
1. Check all other gauges and meters (besides the
suspect). If none of them are working, check or replace
F5 (carrier) or F9 (superstructure).
2. Check the gauge or meter, its sensing component, and
circuit for continuity problems and other problems. A
sender is probably at fault when it shows infinite
resistance, or resistance out of specifications for
condition. Repair any faulty gauge, meter or other
component. Repair wiring if faulty.
The following carrier and superstructure circuit designs
(Table 3-11) apply (connecting wiring and passage through
swivel slip ring -- as applicable -- is understood):
Table 3-11
Lights Circuit
Head Lights
HEADLIGHTS switch, dimmer switch,
F21, F22, F23, or F24, lamps,
grounds
Tail Lights
HEADLIGHTS switch, F19 or F20,
lamps, grounds
Marker Lights
HEADLIGHTS switch, F19 or F20,
lamps, ground
Gauge Lights
HEADLIGHTS switch, F4, lamps,
grounds
Turn Signal
Lights
F13, flasher, turn signal switch, relays
K109, K110, K111, or K112, lamps,
grounds. Suspect turn signal switch if
hazard light circuit functions properly.
Hazard Lights
F13, flasher, hazard lights switch,
relays K109, K110, K111, or K112,
lamps, grounds. Suspect hazard
lights switch if turn signal lights circuit
functions properly.
Stop Lights
F14, stop light switches, turn signal
switch, K109, K110, K111, or K112,
lamps (suspect stop circuit problem if
turn signal or tail light function works),
grounds
Beacon Light
F7, BEACON light switch, lamp,
ground. Parallel circuit to LED
indicator in switch to ground
Cab Dome Light
F10, switch on dome light, parallel
circuit through door switch, lamp,
ground
Lights Circuit
Boom Flood
Lights
F1, BOOM light switch, lamps,
grounds. Parallel circuit to LED
indicator in switch to ground
Work Lights
F2, WORK light switch, lamp,
grounds. Parallel circuit to LED
indicator in switch to ground
Cab Dome Light
F3, switch on dome light, lamp,
grounds
Gauge Lights
F3, PANEL DIM control, lamps,
grounds
Beacon Light
F8, lamp, ground. Parallel circuit to
LED indicator in switch to ground
Gauge/Meter Circuit
Voltmeter F5/F9, voltmeter, ground
Fuel Level
Gauge
F5/F9, gauge. Gauge is grounded.
Branch from gauge to sending unit in
fuel tank to ground
Engine oil
Pressure Gauge
F5/F9, gauge. Gauge is grounded.
Branch from gauge to oil pressure
sending unit to ground
Engine Coolant
Temperature
Gauge
F5/F9, gauge. Gauge is grounded.
Branch from gauge to coolant
temperature sending unit to ground
Reference Only
