Manitowoc Grove TMS700E User Manual

Grove Published 01-29-2015, Control # 512-01 4-7
TMS700E SERVICE MANUAL BOOM
4
10. Remove the four bolts and hardened washers securing
the guide block to the inner top of Section 1. Remove the
guide block and shim(s), noting quantity of shims.
11. Remove the four bolts, hardened washers, and nuts
securing each top wear pad keeper plate to Section 1.
Remove the keeper plates.
12. Remove the eight bolts and hardened washers securing
the bottom and side wear pad keeper plates to Section
1. Remove the keeper plates.
13. Remove the four bolts and hardened washers securing
each front top wear pad to Section 1. Remove the wear
pads and shims, noting quantity, size, and location of
shims.
14. Lift up on the front of Section 2 and remove the bottom
and side wear pads and shims from Section 1, noting
quantity, size, and location of shims.
15. Continue to pull the assembly from Section 1 removing
the top rear wear pads from Section 2 as they clear
Section 1.
16. Remove the two flat head screws securing the rear side
wear pads to Section 2. Remove the wear pads and
shims, noting quantity and size of shims.
17. Remove the mounting plates from the lugs on the lower
cylinder rod.
18. Tag and disconnect the hydraulic hoses and tubes from
the telescope cylinders and the two cam valves. Cap or
plug all openings.
19. Remove the three bolts, hardened washers, and nuts
(early models only) securing each cam valve to its
mounting plate and remove the valves.
20. Place blocking under the lower cylinder barrel.
21. Remove the four bolts and hardened washers securing
each lower cylinder barrel mounting plate to Section 2.
22. Remove the five bolts and hardened washers securing
each upper cylinder rod mounting plate to Section 2.
23. Remove the nuts and hardened washers from the four
extend cable threaded ends. Remove them from the
mounting bracket. Tape or ty-wrap the ends of the
cables to the telescope cylinder to prevent damage to
the cables.
24. On the left side of Section 2, remove the valve pusher
rod from the tube.
25. On the right side of Section 2, remove the valve pusher
rod. Disassemble as necessary.
NOTE: Together boom Section 3 and Section 4, and
telescope cylinders weigh approximately 4861 kg
(10,717 lb).
26. Slide the assembly out of Section 2 part way.
27. Remove the four bolts and hardened washers securing
the guide block to the inner top of Section 2. Remove the
guide block and shim(s), noting quantity of shims.
28. Remove the four bolts and hardened washers securing
each top wear pad keeper plate to Section 2. Remove
the keeper plates.
29. Remove the seven bolts and hardened washers
securing the bottom and side wear pad keeper plates to
Section 2. Remove the keeper plates.
30. Remove the four bolts, hardened washers, and nuts
securing each front top wear pad to Section 2. Remove
the wear pads and shims, noting quantity, size, and
location of shims.
31. Lift up on the front of Section 3 and remove the bottom
and side wear pads and shims from Section 2, noting
quantity, size, and location of shims.
32. Continue to pull the assembly from Section 2, removing
the top rear wear pads from Section 3 as they clear
Section 2.
33. Remove the two flat head screws securing the rear side
wear pads to Section 3. Remove the wear pads and
shims, noting quantity and size of shims.
34. Remove the two bolts and hardened washers securing
the bottom wear pad to Section 2 and remove the wear
pad.
35. If necessary, remove both grease fittings, connectors,
and grease lines from the rear of Section 2.
36. Remove the mounting plates from the lugs on the lower
cylinder barrel and from the upper cylinder rod.
37. Remove four bolts and hardened washers securing
each retract cable sheave mount in the rear of Section 3.
Lay the sheave mounts in the rear of Section 4.
38. Place blocking under the upper cylinder barrel.
39. Remove the four bolts and hardened washers securing
each upper cylinder barrel mounting plate to Section 3.
NOTE: T
ogether boo
m Section 4 and telescope cylinders
weigh approximately 3225 kg (7110 lb).
40. Slide the assembly out of Section 3 part way.
41. Remove the four bolts and hardened washers securing
the guide block to the inner top of Section 3. Remove the
guide block and shim(s), noting quantity of shims.
42. Remove the four bolts, hardened washers, and nuts
securing each top wear pad keeper plate to Section 3.
Remove the keeper plates.
43. Remove the seven bolts and hardened washers
securing the bottom and side wear pad keeper plates to
Section 3. Remove the keeper plates.
