Grove Published 01-29-2015, Control # 512-01 5-7
TMS700E SERVICE MANUAL HOIST AND COUNTERWEIGHT
5
6019
Main Hoist is Aligned to the Right Hand Sheave
Locating Centerline with Square
Auxiliary Hoist is Aligned to the Center Sheave
FIGURE 5-3
Reference Only
