INTRODUCTION TMS700E SERVICE MANUAL
1-6 Published 01-29-2015, Control # 512-01
Table 1-1 Axle Weight Distribution Table
Description
CG T o CL
R ea r Bo g ie
cm (in)
W e i g h t
kg (lb)
F r o n t A x le
kg (lb)
R e a r A x l e
kg (lb)
Maximum Tire & Wheel Loads Allowed 23224(51200) 27216(60000)
Maximum Axle Loads Allowed 23224(51200) 27216(60000)
Standard Carrier Assy (8x4x4) 304.60(119.92) 18919(41708) 10220(22530) 8699(19178)
Superstructure Assy with main and aux
hoists, w/cables
-51.69(-20.35) 6422(14157) -589(-1298) 7010(15455)
Boom Assy w/pivot pins, 2 over 3
sheaves, RCL
489.46(192.70) 8241(18169) 7154(15771) 1088(2398)
Lift Cylinder and lower shafts 210.82(83.00) 791(1743) 296(652) 495(1091)
Complete Basic Machine: Carrier Ass'y,
S/S Ass'y, 4-Section Boom, Cummins
ISX 11.9 2010 Engine, 445/65R22.5
Goodyear Front Tires, 315/80R22.5
Goodyear Rear Tires, Full Fuel and
Hydraulic Oil, cable on both hoists
280.21(110.32) 34372(75777) 17080(37655) 17292(38122)
Boom Extensions
10 - 17 m (33 - 56 ft) Bi-fold Boom
Extension
571.30(224.92) 1132(2495) 1147(2528) -15(-33)
Boom Extension Carrier Brackets 467.36(184.00) 133(293) 110(243) 23(50)
Aux Boom Nose 1097.28(432.00) 59(130) 115(253) -56(-123)
6.1 m (20') Boom Extension Insert w/RCL
(pinned at boom nose)
407(898)
Counterweights
5500 lb counterweight on superstructure
- master
-227.03(-89.38) 2495(5500) -1004(-2214) 3499(7714)
5500 lb counterweight on superstructure
- slab
-227.03(-89.38) 2495(5500) -1004(-2214) 3499(7714)
5500 lb counterweight on superstructure
- slab
-227.03(-89.38) 2495(5500) -1004(-2214) 3499(7714)
5500 lb counterweight stowed on deck -
master
481.03(189.38) 2495(5500) 2128(4692) 367(808)
5500 lb counterweight stowed on deck -
slab
481.03(189.38) 2495(5500) 2128(4692) 367(808)
5500 lb counterweight stowed on deck -
slab
481.03(189.38) 2495(5500) 2128(4692) 367(808)
Rigging Equipment
7.5 t (8.3 ton) Headache Ball (Swivel) - in
stowage tray
830.58(327.00) 161(355) 237(523) -76(-168)
7.5 t (8.3 ton) Headache Ball (Swivel) -
tied to front bumper
942.34(371.00) 161(355) 269(593) -108(-238)
36 t (40 ton) Hookblock (3 sheave) - tied
to front bumper
955.04(376.00) 373(823) 632(1394) -259(-571)
45 t (50 ton) Hookblock (3 sheave) - tied
to front bumper
955.04(376.00) 458(1010) 776(1711) -318(-701)
55 t (60 ton) Hookblock (5 sheave) - tied
to front bumper
955.04(376.00) 581(1280) 983(2168) -403(-888)
Rigging 170.18(67.00) 45(100) 14(30) 32(70)
Reference Only
