Grove Published 01-29-2015, Control # 512-01 5-15
TMS700E SERVICE MANUAL HOIST AND COUNTERWEIGHT
5
FIGURE 5-10
2
1
3
2
4
5
7
8
6
Item Description
1 CWT Removal Panel
2 Removal Cylinder
3 Slab Attach Pin
4 Cylinder Attach Pin
Item Description
5 Box Attach Pin
6 2495 kg (5500 lb) Slabs
7 2495 kg (5500 lb) Standard Box
8 Jack Screws
Reference Only
