TMS700E SERVICE MANUAL POWER TRAIN
7
Air Cleaner Body
Before installing the filter element, remove foreign material
(leaves, lint or other foreign matter) that may have collected
inside the air cleaner body. Inspect the inside of the body for
dents or other damage that would interfere with air flow or
with the fins on the element or inside the body. Repair any
body dents, being careful not to damage the sealing
6786
1
2
3
4
5
6
7
QSM AIr Intake Installation
1. Air Cleaner
2. Mounting Band
3. Air Inlet Hood
4. Service Indicator
5. Reducing Elbow
6. Tube
7. Vacuator Valve
1
2
3
4
5
6
7
ISX AIr Intake Installation
1. Air Cleaner
2. Mounting Band
3. Air Inlet Hood
4. Service Indicator
5. Reducing Elbow
6. Tube
7. Elbow
Reference Only
