POWER TRAIN TMS700E SERVICE MANUAL
7-32 Published 01-29-2015, Control # 512-01
1
2
8
5
3
4
1
6, 7
3
2
8
5
4749
FIGURE 7-12
10
9
10
9
Item Description
1 Clutch Assembly
2 Clutch Pedal Adjusting Lever
3 Governor Spring
4 Pilot Bearing (ref.)
5 Crank
6 Lockwasher
7Bolt
8 Clutch Release Shaft and Yoke
9 Throw Out Bearing
10 Throw-Out Bearing Grease Fitting
Item Description
Reference Only
