UNDERCARRIAGE TMS700E SERVICE MANUAL
8-18 Published 01-29-2015, Control # 512-01
FIGURE 8-10
2
1
5
6
4
1
8
3
4
6
5
7
2
3
2
Item Description
1Drive Axle
2 Air Brake Chamber
3 Torque Rod
4 Lower Saddle Assembly
Item Description
5 Air Bags
6 Walking Beam
7 Shock Absorber
8 Drive Line
Reference Only
