LUBRICATION TMS700E SERVICE MANUAL
9-4 Published 01-29-2015, Control # 512-01
Table 9-1: Standard Lube Symbol Chart
Table 9-2
Lube Description
The following describe the lubrication points and gives the
lube type, lube interval, lube amount, and application of
each. Each lubrication point is numbered, and this number
corresponds to the index number shown on the Lubrication
Chart (refer to Figure 9-1 through 9-3, Table 9-1 and Table 9-
2).
Symbol Description
AFC Antifreeze/Coolant - 50/50 Blended, Fully Formulated - SAE Grade J1941
EO Engine Oil - SAE 15W-40, API Service Classification CJ-4. (CI-4 for pre-2007 ISM engines)
EP-MPG Extreme Pressure Multipurpose Grease - Lithium Soap Base, NLGI Grade 2.
SGL-5 Synthetic Gear Lubricant - SAE Grade 50, API Gravity 23.
HYDO Hydraulic Oil - Must meet John Deere Standard JDM-J20C, Allison C4, and ISO 4406 level.
SSGL-5 Semi-Synthetic Gear Lubricant - SAE Grade 80W-90, API Service Designation GL-5.
ASC Anti-Seize Compound - Military Specifications MIL-A-907E.
EP-OGL Open Gear Lubricant - LPS Dry Force 842 Moly Lube
EPGL-5H Extreme Pressure Gear Lubricant - SAE Grade 80W-140
LCC Liquid Coolant Conditioner
DEF Diesel Exhaust Fluid
SCA Supplemental Coolant Additive
Lubrication Description Lube Specification
50/50 Fully Formulated Anti-Freeze Coolant 6829101130
Engine Oil SAE 15W40, CJ4 6829104182
Engine Oil SAE 15W40, CI4 6829003483
Extreme Pressure Multi-Purpose Grease 6829003477
Synthetic Gear Lube 6829013433
Hydraulic Oil 6829006444
Semi-Synthetic Gear Lube 6829012964
Anti-Seize Compound 6829003689
Open Gear Lube 6829104478
EPGL Gear Lube 6829006240
Liquid Coolant Conditioner 6829012858
Diesel Exhaust Fluid
80019225
Wire Rope See Service Manual
CAUTION
The following lube intervals are to be used as a guideline
only. Actual lube intervals should be formulated by the
operator to correspond according to conditions such as
continuous duty cycles and/or hazardous environments.
Reference Only
