BOOM MLC165-1 SERVICE/MAINTENANCE MANUAL
4-4
Published 05-26-17, Control # 238-02
Figure 4-3
• 80.0° - Start of Spring Cushioning—see View B
• 89.5° - Physical Stop (springs solid)—see View C
Item Description
1 Boom Butt
2 Physical Boom Stop (2)
3Strut
4 Outer Tube
5 Inner Tube
6 Rod End
7 Boom Stop Pin
M100470
View A
1
2
3
1
View C
Physical Stop
View B
Start of Cushioning
6
7
5
4
