HOISTS MLC165-1 SERVICE/MAINTENANCE MANUAL

5-38

Published 05-26-17, Control # 238-02

Item Description

1Drum 3

2 Pressure Rollers

3 Spring (2)

4 Compression Rod (threaded)(2)

4a Hex Nut (4)

4b Flat Washer (2)

4c Hex Nut (4)

5 Screw with Washer and Nut (4)

6 Bracket

A View of Pressure Roller Assembly Installed

B View of Pressure Roller Assembly Compressed

for Servicing

Figure 5-27. Pressure Roller (Drum 3)

STORED

CAGI NG

View A

View B
