Manitowoc MLC165-1 - Page 172

Reference Only
HOISTS MLC165-1 SERVICE/MAINTENANCE MANUAL
5-50
Published 05-26-17, Control # 238-02
Figure 5-34. Free Fall Brake
Item Description
1 Swivel Fitting in SUPPLY Port
2Cover
3 Supply Hose
4 Case Drain Hose
5 Brake Housing
6 Bolt: 18 each M10 x 8,8 Threads x 35 mm long
Right End of Either Load Drum in Right Side Enclosure
