Reference Only
SWING SYSTEM MLC165-1 SERVICE/MAINTENANCE MANUAL
6-4
Published 05-26-17, Control # 238-02
Figure 6-3. Swing Drive
Item Description
1Swing Motor
2Swing Brake
3 Swing Gearbox
4 Brake Release Hose
5 Brake Release Fitting (04 ORFS)
