Manitowoc MLC165-1 Service Maintenance Manual

Reference Only
Manitowoc Published 05-26-17, Control # 238-02 1-9
MLC165-1 SERVICE/MAINTENANCE MANUAL INTRODUCTION
1
Legend for Figure 1-3
Item Description
1-10
Figure 1-2
11 Crane Counterweights
12 Counterweight Handling Cylinder
13 Boom Hoist Wire Rope
14 Mast
15 Self-Assembly Cylinder
16 Engine Enclosure
17 Left Enclosure with Platform (see NOTE)
18 Handrail (optional both sides)
19 Drum 2 (rear drum)
20 Drum 1 (front drum)
21 operator cab Platform and Railings
22 Left Crawler
23 Carbody Jack (4)
24 Carbody Counterweight (Series 2 option)
25 Engine Air Cleaner
NOTE The Left Enclosure covers the following:
• Drum 1 Drive (front drum)
• Pilot Signal Manifold
• Main Control Valve Manifold
• Node 3
• Drum 2 Drive (rear drum)
• Swing Drive
• Pilot Brake and Pawl Manifold
• Hydraulic Tank
• Hydraulic Pumps and Pump Drive
• Engine and Pump Drive
