MLC165-1 SERVICE/MAINTENANCE MANUAL ELECTRICAL SYSTEM
3
3
P12-24 DI-22
Engine Run/Start 0 Volts Off; 24 Volts On CAN92-5-32
P12-25 DI-7
Travel Park Switch 0 Volts Off; 24 Volts On CAN92-3-64
P12-26 DI-17
Boom Hinge Pins Disengage 0 Volts Off; 24 Volts On CAN92-5-1
P12-31 CANH
CAN High Data Line to Graphical Display N/A
P12-32 CANL
CAN Low Data Line to Graphical Display N/A
P12-33 DI-19
DPF Inhibit 0 Volts Off; 24 Volts On CAN92-5-4
P12-34 DI-21
DPF Regen Initiate 0 Volts Off; 24 Volts On CAN92-5-16
P12-35 DI-8
Mast Cylinders Retract Switch 0 Volts Off; 24 Volts On CAN92-3-128
P12-36 DI-18
Mast Cylinders Extend Switch 0 Volts Off; 24 Volts On CAN92-5-2
