Manitowoc Published 05-26-17, Control # 238-02 3-23
MLC165-1 SERVICE/MAINTENANCE MANUAL ELECTRICAL SYSTEM
3
3
33-p AI-7
Handle 2 (Drum 2) Up Pilot Pressure Sender
1 Volt at 0 psi (0 bar),
5 Volts at 870 psi (60 bar)
CAN5-6
1
33-r AI-8
Handle 2 (Drum 2) Down Pilot Pressure Sensor
1 Volt at 0 psi (0 bar),
5 Volts at 870 psi (60 bar)
CAN5-8
1
33-s
24 Volts
Handle 2 (Drum 2) Up and Down Pilot Pressure
Sensor
24 Volts Nominal
J4/W34 Receptacle - Solenoids and Swing Motor Speed Sensor
34-A Ground
Drum 4 Up HS-311
Ground
34-B DO-11
Drum 4 Up HS-311
0 Volts Off; 24 Volts On
CAN21-2-4
34-C Ground
Drum 4 Down HS-312
Ground
34-D DO-12
Drum 4 Down HS-312
0 Volts Off; 24 Volts On
CAN21-2-8
34-E Ground
Drum 1 Up HS-313
Ground
34-F DO-13
Drum 1 Up HS-313
0 Volts Off; 24 Volts On
CAN21-2-16
34-G Ground
Drum 1 Down HS-314
Ground
34-H DO-14
Drum 1 Down HS-314
0 Volts Off; 24 Volts On
CAN21-2-32
34-J Ground
Drum 2 Up HS-315
Ground
34-K Ground
Drum 3 Down HS-318
Ground
34-L Ground
Drum 3 Up HS-317
Ground
34-M DO-17
Drum 3 Up HS-317
0 Volts Off; 24 Volts On
CAN21-3-1
34-N Ground
Drum 2 Down HS-316
Ground
34-P DO-16
Drum 2 Down HS-316
0 Volts Off; 24 Volts On
CAN21-2-128
34-R DO-15
Drum 2 Up HS-315
0 Volts Off; 24 Volts On
CAN21-2-64
34-S DO-18
Drum 3 Down HS-318
0 Volts Off; 24 Volts On
CAN21-3-2
34-T Ground
Select Handle 3 to Drum 4 Up HS-319
Ground
34-U DO-19
Select Handle 3 to Drum 4 Up HS-319
0 Volts Off; 24 Volts On
CAN21-3-4
34-V Ground
Select Handle 3 to Drum 4 Down HS-320
Ground
34-W DO-20
Select Handle 3 to Drum 4 Down HS-320
0 Volts Off; 24 Volts On
CAN21-3-8
34-X Ground
Select Handle 4y to Drum 2 Up HS-321
Ground
34-Z DO-21
Select Handle 4y to Drum 2 Up HS-321
0 Volts Off; 24 Volts On
CAN21-3-16
34-a Ground
Select Handle 4y to Drum 2 Down HS-322
Ground
34-b DO-22
Select Handle 4y to Drum 2 Down HS-322
0 Volts Off; 24 Volts On
CAN21-3-32
34-c Ground
Select Handle 4y to Drum 3 Up HS-323
Ground
34-d DO-23
Select Handle 4y to Drum 3 Up HS-323
0 Volts Off; 24 Volts On
CAN21-3-64
34-e Ground
Select Handle 4y to Drum 3 Down HS-324
Ground
34-f DO-24
Select Handle 4y to Drum 3 Down HS-324
0 Volts Off; 24 Volts On
CAN21-3-128
34-g Ground
Jumper to Node Select 2
Ground
34-j NS-2
Node Select 2 Jumper to Ground
0 Volts (With Jumper)
34-n 24 Volts
Swing Motor Speed Sensor
24 Volts Nominal
34-p EC3A
Swing Motor Speed Sensor
1.2 or 3.2 Volts Not
Moving;
2.2 Volts Moving
CAN38-3
2
34-r Ground
Swing Motor Speed Sensor Ground
34-s EC3B
Swing Motor Speed Sensor
1.2 or 3.2 Volts Not
Moving;
2.2 Volts Moving
CAN38-3
2
J6/W36 Receptacle - Pressure Sensors, Limits, Speed Sensors, Mast Angle Sensor, and Motor Control
36-A Ground
Swing System Left/Right Pressure Sensor
Ground
