3. Insert the CD delivered with the masibus Vibration Monitor device to the local CD ROM
drive of the PC.
4. The GUI of the CD starts
5. Start in the menu mPC Tool setup Program and follow the installation steps according to
the instructions on the screen Or Refer Help document from the CD itself.
6. The mPC Tool is now installed.
Uninstalling the mPC Tool
To uninstall the mPC Configuration Tool follow the steps as below.
1. Select Start > Control Panel > Software
2. Press the button Remove in the list beside the entry mPC Tool.
3. Answer the following question with yes.
C.3.3 Overview mPC Configuration Tool
The section mPC Tool provides information on how to configure the device parameters of a
Profibus & Modbus. Serial IO or Data Mapping and which information can be gained from the
diagnostic pane of the mPC Tool.
Note: The scope of functions of the mPC Tool depends from the installation setup used. This
description includes a broad range of functional options, which are not necessarily included in
every single installation setup.
C.3.3.1 Starting mPC Tool
1. Make sure the device is correctly supplied with power and is Operational.
2. Start the mPC Tool.
3. Select Start > Programs > Masibus Products > mPC Tool > mPC Tool.exe
4. Or it can be start by Desktop Shortcuts.
C.3.3.2 Introduction to the Dialog Structure
The graphical user interface of the mPC Tool is composed of different areas and elements
listed hereafter:
Refer Screenshots available in next section.
Default Project Load :
1. Copy “Vibration-VMS4SE.mnt” Project from CD to the given path in User‟s windows OS
(Directory:C:\Programfiles\Masibus Products\mPCTool\Data).
2. Connect Configuration cable between Vibration Monitor Profibus port (DB9-Female
connector) and User‟s PC serial communication comport.
3. Open mPCTool.exe
4. Select Open Project from Menu and select the template as Vibration-VMS4SE.mnt
