Table 6 Pin Details of Relay Cable (Three Output Terminals)
DIGITAL OUTPUT - RELAY ( DO - RL ) (Three Output Terminals)
Sr. No.
Connector Pin No.
Pin Detail
Ferrule No.
1
1
NOT CONNECTED
1
2
2
COMMON 1
2
3
3
NO -1
3
4
4
NC -1
4
5
5
COMMON 2
5
6
6
NO -2
6
7
7
NC -2
7
8
8
COMMON 3
8
9
9
NO -3
9
10
10
NC -3
10
11
11
COMMON 4
11
12
12
NO -4
12
13
13
NC -4
13
14
14
COMMON 5
14
15
15
NO -5
15
16
16
NC -5
16
17
17
COMMON 6
17
18
18
NO -6
18
19
19
NC -6
19
20
20
COMMON 7
20
21
21
NO -7
21
22
22
NC -7
22
23
23
COMMON 8
23
24
24
NO -8
24
25
25
NC -8
25
