User Manual 15
VMS4SE(Vibration Monitor)
REF NO: mVMA/om/101
Issue No: 01
SOFTWARE
MEMORY
Non volatile, restored after power loss
3.4 Communication Specification
NO. OF COMMUNICATION
PORT
2-RS485(COM-1 and COM-2) . COM2 is Optional
COMMUNICATION TYPE
Half duplex/Asynchronous
COMMUNICATION
PROTOCOL
MODBUS RTU (Baud rate and Parity bit are selectable). All
parameters are Configurable through MODBUS Protocol.
MAXIMUM NO. OF UNITS
32
COMMUNICATION ERROR
DETECTION
CRC Check
3.5 PROFIBUS Communication (Optional) *
MODE
Profibus DP Slave
BAUD RATE
9600, 19.2K, 44.45K, 93.75K, 187.5K, 500K, 1.5M, 12M bps(Auto Detected)
ADDRESS
Configurable through Configuration Software (0 to 125 Only)
NETWORK
CAPACITY
 Multi-drop up to 31 modules, Plus a host, without a repeater
 Up to 125 modules plus a host if four repeaters are used (i.e. one for every
31 nodes)
COMMUICATION
DISTANCE
Up to 1200 meters without a repeater using Type A wire (<30pF/m).
 1200m @ 115Kbps or less
 1000m @ 187.5Kbps
 400m @ 500Kbps
 200m @ 1.5Mbps
 100m @ 12Mbps
Note : * - With Profibus communication , CE marking is not applicable/valid.
3.6 HMI Interface (Optional)
NO. OF COMMUNICATION PORT
1-RS-232 (HMI)
COMMUNICATION TYPE
Half duplex/Asynchronous
COMMUNICATION PROTOCOL
MODBUS RTU (19.2kpbs, 8-data bits, 2-stop bits)
CONNECTABLE NO. OF UNITS
1
COMMUNICATION ERROR DETECTION
CRC Check
3.7 Network Connectivity (Optional)
NO. OF COMMUNICATION PORT
1(RJ-45)
TRANSMISSION SPEED
10 Mbps
NETWORK PROTOCOL
TCP/IP
APPLICATION PROTOCOL
MODNET
3.8 Data logging (Optional)
Data logging Memory Type
Flash Nonvolatile Memory (32 MB)
Data logging type
Periodic and Event(Alarm)
Periodic Memory Size
25 MB
Event Memory Size
7 MB
RTC Time format
DD/MM/YY – HH:MM:SS
Periodic Logging sampling time
1 Second minimum
Event polling time
1 second
USB Port *
1(USB mass storage device , USB 2.0)
USB Function
For retrieving logged data only
Max. USB Mass storage device size
Upto 4 GB
USB Mass storage device format
 FAT16 (Recommended)
