Note 3:
1) None means no AO(Analog Output)(Retransmission Output) is assigned to particular channel.
2) AO O/p number = 0 represents “None”. AO O/p Number = 1 to 8 represents
“Retransmission No. 1 to Retransmission No. 8”. For more details refer Table 20.
3) In “Retransmission mapping” parameter, maximum 2 numbers of Analog Outputs can be
assigned to each channel. i.e. each channel can have maximum two number of analog
outputs simultaneously. See the example below.
Example 1: If Retransmission mapping for channel 1 = 0102 H, it means Retransmission
output number 1 and output number 2 are assigned to channel 1. And output of channel 1 can
be taken on analog output (retransmission output) number 1 and number 2.
Example 2: If Retransmission mapping for channel 3 = 0001 H, it means Retransmission
output number 1 is assigned to channel 3. And output of channel 3 can be taken on analog
output (retransmission output) number 1.
Table 20 AO(Analog Output)(Retransmission Output) description
