Masibus Automation VMS4SE User Manual

User Manual 41
VMS4SE(Vibration Monitor)
REF NO: mVMA/om/101
Issue No: 01
a.s.Hy
Prog
Alarm Set
point
Hysteresis
Alarm Set Point Hysteresis for all
Channels
0001(for all
channels)
-
(A.S.Hy)
(PROG)
CSP
Prog
Control Set
Point
Control Set Point for All Channel
0100(for all
channels)
Control
Output is
required
(CSP)
(PROG)
C.S.Hy
Prog
Hystresis
Control Set point Hysteresis for all
Channels
0001(for all
channels)
Control
Output is
required
(C.S.Hy)
(PROG)
2) Configuration Mode :
Pressing MENU key DATA window shows Conf (Conf) message and Parameter window shows
MODE(Mode) message. Press MENU key again PARAMETER window shows pWd (PWD)
message(if and only if password is set other than zero. Otherwise it will enter into sub menu),
press MENU Key to enter into edit mode of password and then press INCREMENT key or
DECREMENT key to modify the password and then press MENU Key to enter into Configuration
Mode. DATA window shows Inpt (Inpt) message and PARAMETER window shows conf
(CONF) .Press MENU Key to enter into sub menu of Input configuration. DATA window shows
Inp.t (Inp.t) and PARAMETER window shows in.conf (IN.CONF). Press MENU Key to enter
into sub menu of parameter. DATA window shows ACC (Acceleration) and PARAMETER window
shows inp.t (INP.T) along with channel number then use MENU Key to enter into editing
mode and use INCREMENT and DECREMENT key to modify value. OR press INCREMENT key
again to change Input type for Channel 2. After pressing INC key many times, the message on
Channel Window shows al,(AL) which means user can modify parameters for all channels at
once(AL = ALL). ESCAPE KEY is used to come out INP.T.
Table 13 Configuration Mode Parameters
Configuration Mode
Data
Window
Parameter
Window
Name
Setting name and description
Default value
Shows
only if
Symbol
Symbol
0
pwd
Program Mode
Password
0 to 9999
0
Password
is other
than zero
0
(PWD)
Inpt
conf
Input
Configuration
Different parameters for Input
Configuration
-
-
(Inpt)
(CONF)
Do
conf
DO(Digital
Output)
Configuration
Different parameters for DO (Digital
Output) Configuration
-
Any of
Digital
Output is
required
(do)
(CONF)
Ao
conf
AO(Analog
Output)
Configuration
Different parameters for AO (Analog
Output) Configuration
-
Analog
Output is
required
(Ao)
(CONF)
Comm
conf
Communication
Configuration
Different parameters for
Communication Configuration
-
-
(Comm)
(CONF)
Disp
conf
Display
Configuration
Different parameters for Display
Configuration
-
-
(diSP)
(CONF)
Log
conf
Logging
Configuration
Different parameters for Logging
Configuration
-
Logging is
required
(LoG)
(CONF)
